H06-13 Inorganic Zinc-Rich Primer is a coating with excellent anti-corrosion properties that can effectively prevent oxidation and corrosion of metal surfaces. It is particularly suitable for steel structures in highly corrosive environments, providing long-term protection and extending the service life of equipment.
The inorganic zinc rich primer is composed of epoxy resin, phosphorohthalein powder and auxliaries, and polyurethane is used as curing agentWhenin use, mix according to the specified proportion, and use up within the specified time after fully mixing.
FEATURE：
The inorganic zinc primer paint film has high hardness and has electrochemical protection effect, it is resistant to high temperatures and does notaffect welding performance, it has excellent drying performance; it has high adhesion and good mechanical properties.
USES:
Apply to ships, petroleum, electric power, Bridges, sewage, steel structure factory building, mechanical equipment, locomotive, container equipment facilities make using of the anti-corrosion primer.
H06-13 INORGANIC ZINC-RICH PRIMER Tethnical Parameter
ITEM
NORM
Packaging specification
Paint: 20KG
Curing agent: 2KG
Appearance
Liquid
Film color and appearance
Gray, Matte
Dry time,h,(25℃)
Surface dry h≤4
Hard dry h≤24
Adhesive force,grade≤
2
Flexible,mm≤
1
Impact force,kg.c㎡
50
Salt fog resistance test,96h
No change
Salt water resistance test (soak In 3% NaCl salt water for 96h)
No change
Acid resistance (soak in 3% H₂SO₄ liquid for 48h)
No change
Alkali resistance (soak in 5% NaOH liquid for 48h)
No change
Physical Parameters and Construct Specifications for Reference
Mixing ratio
Paint : curing agent=10:1
Life time after mix
2h
Density after mix
About 1.8kg/L
Flashing point
≤60°
Each film thickness
Dry film 40um,wet film 60um
Theoretical coverage
0.3g/m
Advise coating layer
2 Coats
Re-coat interval
4h ,exceed 7days should be processed by polishing
Surface treatment
The surface of the base must be clean and dry , without loose paint, grease and other dirt , sandblasting or grinding to Sa2 grade.
Construction environment
Construction temperature is 5~40 ℃
Air relative humidity less than 85% .
The substrate surface humidity is 3℃ higher than the dew point
Avoid construction in the rain, snow, fog weather.
Coating method
Brush,Spray, Roller coating
Storage life
1.5 Year
Certificate
Guangdong Huaren Chemical industry Co., Ltd. products has passed ROHS certificate, ensure the products pass Europe standard ; has passed ISO9001:2015 certificate, ensure supply stable quality to our suppliers.
Service Advantages
Customization
Customized various performance coatings,according to the use situation,Design appropriate process and coating application plan.
Large-scale production capacity
The annual output of 30000 tons of coating and 20000 tons of resin has a large production baseof 20000 square meters.
Construction and technical services
Professional construction team, providing design, construction and technical guidance.
Timely delivery service
The subsidiary company of dangerous goods transportation company owned by the company can timely distribute large-scale key project projects.
